The 30Ah 2C/2C sodium-ion battery offers a nominal voltage of 3.0V, weighs 990g, and operates efficiently in temperatures ranging from -20 to 55°C, with a cycle life of 3000.
Specification | QPN30CA |
Rated Capacity | 30Ah@1C |
Nominal Voltage | 3.0V |
ACR | ≤1.2mΩ |
Cell Weight | (990±20)g |
Operating Temperature | -20~55℃ |
Maximum Continuous Discharge Current | 2C |
Maximum Continuous Charge Current | 2C |
Cycle life | 3000 |
Typical Dimension | 27mm*148mm*134mm |
Balanced 2C Charge/Discharge: The cell supports continuous 2C currents, delivering robust performance at approximately 60 A for both charging and discharging—ideal for mid‑power applications.
Lightweight with High Capacity: Weighing just under 1 kg while providing 30 Ah makes this prismatic form factor a space- and weight-efficient solution for numerous battery pack designs.
Excellent Cycle Durability: With a rated lifespan of around 3,000 cycles, this cell ensures longevity for products requiring frequent charge cycles.
Wide Thermal Resilience: Operating reliably from –20 °C to +55 °C, it’s suitable for settings from temperate climates to cold-weather environments.
Affordable Sodium-Based Chemistry: Leveraging abundant resources, sodium-ion cells offer cost advantages while retaining respectable energy density and safety.
